Details

x-travel

800 mm

y-travel

800 mm

z-travel

800 mm

control

SIEMENS 840D POWERLINE

turning speeds

8000 1/min

spindle

37 / 25 kW

tool taper

HSK-A 100

tool change unit

120

size of pallet

630 x 500mm mm

b-axis

360 x 1 °

Feed x/y/z

60 m/min

rapid travel x/y/z

60.000 mm/min

total power requirement

80 kVA

weight of the machine ca.

15,6 t

dimensions of the machine ca.

8 x 6,2 x 3,2 m

internal coolant system feed

dimensions for transport

4,6 x 2,4 x 2,7 m

Zubehör

Chip Conveyor

Description

NC-round-table
pallet-changer (2 pallets),
Internal Coolant Supply 40 bar, new
Infrared Touch Probe Renishaw
approx. 16.612 h main switch on
apprax. 8.608 Spindle hours
